Sai ovislink krypton c60 chasis 60 kva trifasico sin baterias

Capacity 10-200KVA br/ br/ Main Input br/ br/ Input voltage "380V/400V/415V(line to line)220V/230V /240V(line to neutral)" br/ br/ Input frequency 50/60Hz br/ br/ Power factor ,0.99 br/ br/ Input voltage window -40%~+25% br/ br/ Frequency window 40-70HZ br/ br/ Battery br/ Battery voltage ±240VDC br/ br/ Charger power 20%*Power br/ br/ Charger voltage precision 1% br/ br/ Bypass br/ Bypass voltage "380V/400V/415V, three phase220V/230V/240V, one phase" br/ br/ Bypass voltage window -20%-+15%, full load, settable br/ br/ Bypass overload capabiltiy 125%, long time operation br/ br/ 125% , load ,130%, last for more than 1 hour br/ br/ 130% br/ br/ ,1000%, last for more than 100ms br/ br/ Output br/ Output voltage "380V/400V/415V, three phase220V/230V/240V, one phase" br/ br/ Voltage precision ±0.5% (balance load),±1% (unbalance load) br/ br/ Voltage THD(Total Harmonic Distortion) THD ,1%(linear load),THD ,5%(nonlinear load) br/ br/ Power factor 0.8 br/ br/ Phase tolerance 120°±0.5° (balance and unalance load) br/ br/ Crest factor 3:1 br/ br/ Overload capabiltiy 105%,long time operation br/ br/ 110%, transfer to bypass after 1hour br/ br/ 125%, transfer to bypass after 10 minutes br/ br/ 150%, transfer to bypass after 1 minute br/ br/ ,150%, transfer to bypass after 200ms br/ br/ System br/ System efficiency Normal mode: 95% br/ br/ ECO mode: 99% br/ br/ Battery mode efficiency 95% br/ br/ Display LCD+LED, Touch screen and keyboard br/ br/ IP class IP20 br/ Interface (Communication Ports ) RS232,RS485,Dry contacts,SNMP card,EPO,Generator br/ interface br/ Installation/Connection Top or bottom cable connection br/ br/ Operation temperature 0-40 br/ br/ Storage temperature -25~70 br/ br/ Relative humidity 0-95% (non-comdensing) br/ br/ Noise(dB) ,55dB br/ Weight(KG) 6-module cabinet RM060/10, RM090/15, RM120/20 br/ 150KG br/ 10-module cabinet RM100/10, RM150/15, RM200/20 br/ 180KG br/ PM10 10KVA: 20KG br/ br/ PM15 15KVA: 21KG br/ br/ PM20 20KVA: 22KG br/ br/ Dimension(W*D*H)(mm) 6-module cabinet 600*900*1600 br/ br/ 10-module cabinet 600*900*2000 br/ br/ Module 400*600*133 (10KVA/15KVA/20KVA)
